5.24.2 Setting the Reset Peak Switch

To set the Reset Peak Switch field to YES or NO, proceed as follows:
1. Use the arrow keys to highlight the Reset Peak field for the selected
port.
2. Press the SPACE bar to select YES or NO.
3. Use the arrows keys to highlight the SAVE command at the bottom of
the screen.
4. Press ENTER. The message "SAVED OK" is displayed.
5.25

MODULE STATISTICS MENU SCREEN

The Module Statistics Menu screen,
screens that allow the user to obtain switch statistics about frame traffic
through each interface, to view MIB-II statistics from each interface, and
to view RMON Statistics gathered by the RMON agent embedded in the
6H122-08.
The following menu item on the Module Statistics Menu screen
NOTE
will not display if the operational mode of the module has been
set to SECURE FAST VLAN:
SWITCH STATISTICS
Section 5.15.9
mode.
Access the Module Statistics Menu from the Module Menu screen by
using the arrow keys to highlight the MODULE STATISTICS menu
item and pressing ENTER. The Module Statistics Menu screen displays.
6H122-08 User's Guide
Module Statistics Menu Screen
Figure
provides instructions on setting the operational
5-31, provides access to
5-83
