4.4

USING THE RESET BUTTON

The RESET button located near the upper plastic locking tab of the

module (refer to Figure 4-3) resets the 6H122-08 processor without

affecting the NVRAM.

Pressing the RESET button resets the device, and all current

switching being performed by the module is halted. A module

CAUTION

downtime of up to two minutes will result from this action.

Reset Button

To reset the 6H122-08 processor, press and release the RESET button.

The module processor goes through a reset process of approximately 20

seconds. Additional downtime may be added as the module reenters the

network.

6H122-08 User's Guide

FAST ENET

6H122-08

Figure 4-3 RESET Button

Using the RESET Button

2159-09

4-7
