Chapter 5: Local Management
5.19

ETHERNET INTERFACE CONFIGURATION

Access the Ethernet Interface Configuration screen from the Module
Specific Configuration Menu screen by using the arrow keys to highlight
the ETHERNET INTERFACE CONFIGURATION menu item and
pressing ENTER. The Ethernet Interface Configuration screen displays.
Event Message Line
Module Type: 6H122-08
Slot Number: X
Port
Port
Num
Type
1 FE-100TX
2 FE-100TX
3 FE-100TX
4 FE-100TX
5 FE-100TX
6 FE-100TX
7 FE-100FX
8 FE-100FX
SAVE
Figure 5-25 Ethernet Interface Configuration Screen for the 6H122-08
The following section briefly explains each field of the Ethernet Interface
Configuration screen:
Port Num (Read-Only)
Displays the number of the front panel interface.
Port Type (Read-Only)
Displays the name of the interface installed in ports 1 through 8.
5-64
6H122-08 LOCAL MANAGEMENT
Ethernet Interface Configuration
Link Current
Status Oper. Mode
Link 100Base-TXFD
Link 10Base-TFD
100Base-TXFD
No Link
Link 100Base-TXFD
Link 100Base-TX
No Link 10Base-T
100Base-FXFD
Link
100Base-FX
Link
Firmware Revision:
BOOTPROM Revision: XX.XX.XX
Desired
Oper. Mode
[Auto-Neg]
[100Base-TXFD]
[100Base-TXFD]
[100Base-TXFD]
[100Base-TXFD]
[100Base-TX]
[100Base-FXFD]
[100Base-FX]
EXIT
6H122-08 User's Guide
XX.XX.XX
Advertised Ability
[100Base-TXFD] [Disabled]
[100Base-TXFD] [Enabled]
[100Base-TXFD] [Enabled]
[100Base-TXFD] [Enabled]
[100Base-TXFD] [Disabled]
[100Base-TX] [Enabled]
N/A
N/A
RETURN
2159-23
