1.4.6

Additional Local Management Functions

Local Management also allows the following tasks to be performed:
• Manage any module installed in the 6C105 via a single terminal
connection.
• Assign an IP address and subnet mask to the 6H122-08 and 6C105
chassis.
• Select a default gateway.
• Control local and remote access.
• Designate workstations to receive SNMP traps from the 6H122-08 and
6C105 chassis.
• Configure module specific SNMP MIB objects including the IETF
Bridge MIB objects.
Chapter 5 provides detailed information about Local Management of the
6H122-08, the optional Fast Ethernet Interface Modules and the 6C105
chassis.
1.5

OPTIONAL FEATURES

For 6H122-08 users, the optional Fast Ethernet Interface Modules provide
the ability to select fiber optic ports or add more Twisted Pair ports. The
Fast Ethernet Interface Modules are listed in
P/N Description
Uses RJ45
FE-100TX
connector
Uses SC
FE-100FX
connector
Uses SC
FE-100F3
connector
6H122-08 User's Guide
Table 1-1 Fast Ethernet Interface Modules
Application
Supports Category 5 Unshielded Twisted Pair
(UTP) cabling with an impedance between 85
and 111 ohms.
Supports multimode fiber optic cabling.
Supports single mode fiber optic cabling.
Optional Features
Table 1-1.
