5.20 MODULE SPECIFIC CONFIGURATION MENU
SCREEN
The Module Specific Configuration Menu screen,
user to select one of five screens to configure ports or check system
resources specific to the 6H122-08.
The following menu items on the Module Specific Configuration
NOTE
Menu screen may not display if the operational mode of the
module has been set to SECURE FAST VLAN or 802.1Q
SWITCHING:
PORT REDIRECT FUNCTION
BROADCAST SUPPRESSION (Available in 802.1Q Mode)
Refer to your Release Notes to see if the functionality provided
by the above screens is supported.
Section 5.15.9
mode.
Access the Module Specific Configuration Menu screen from the Module
Configuration Menu screen by using the arrow keys to highlight the
MODULE SPECIFIC CONFIGURATION MENU menu item and
pressing ENTER. The Module Specific Configuration Menu screen
displays.
6H122-08 User's Guide
Module Specific Configuration Menu Screen
provides instructions on setting the operational
Figure 5-26, allows the
5-69
