THE INTERFACE STATISTICS SCREEN

The Interface Statistics screen is used to gather MIB-II statistics for all of
the 6H122-08 interfaces (ports 1 through 6, optional Fast Ethernet
Interface Modules and all backplane interfaces).
Access the Interface Statistics screen by using the arrow keys to highlight
the INTERFACE STATISTICS menu item on the Module Statistics
Menu screen and pressing ENTER. The Interface Statistics screen,
Figure 5-33, displays.
Event Message Line
Module Type: 6H122-08
Slot Number: X
Interface: 1
InOctets:
InUnicast:
InNonUnicast:
InDiscards:
InErrors:
InUnknownProtos:
OutOctets:
OutUnicast:
OutNonUnicast:
OutDiscards:
OutErrors:
OutQLen:
Interface: [XX]
The following definitions explain each field of the Interface Statistics
screen:
Interface (Read-only)
This field displays the Interface number for which statistics are currently
being displayed.
represents ENET 1 of the module. To view other interface statistics, refer
to Section 5.27.1.
6H122-08 User's Guide
6H122-08 LOCAL MANAGEMENT
Name: Fast Ethernet Frontpanel
7500456
6789
0
0
0
0
0
0
0
0
0
0
CLEAR COUNTERS
Figure 5-33 Interface Statistics Screen
