Chapter 3 Installation; Required Tools; Unpacking The 6H122-08 - Cabletron Systems Expansion module 6H122-08 User Manual

Only qualified personnel should install the 6H122-08.
This chapter covers the following items:
•

Unpacking the 6H122-08

• Installing options
• Installing the 6H122-08 into the 6C105 chassis
• Connecting to the network
• Completing the installation
3.1

REQUIRED TOOLS

A Phillips screwdriver is required to install the Fast Ethernet Interface
Modules in the 6H122-08.
3.2 UNPACKING THE 6H122-08
1. Open the box and remove the packing material protecting the module.
2. Verify the contents of the carton as listed in
6H122-08 User's Guide
CHAPTER 3
INSTALLATION
(Section
(Section 3.3)
(Section
(Section
Table 3-1 Contents of 6H122-08 Carton
Item
6H122-08
Manual Accessory Kit
3.2)
(Section
3.5)
3.6)
Table
Quantity
1
1
3.4).
3-1.
3-1
