MODULES
The MODULES menu item provides access to the Module Selection
screen that is used to select individual modules in the chassis for
management purposes.
Access the Module Selection screen by using the arrow keys to highlight
the MODULES menu item and pressing ENTER. The Module Selection
screen displays. Proceed to
5.6

CHASSIS MENU SCREEN

The Chassis Menu screen,
Management screens that allow you to configure and monitor operating
parameters, modify SNMP community names, set SNMP traps, monitor
the 6C105 environmental status, perform port redirect functions, and to
configure the 6C105 for IEEE 802.1Q operation.
6H122-08 User's Guide
Section 5.12.
Figure 5-8, provides access to Local
6C105 LOCAL MANAGEMENT
Chassis Menu
CHASSIS CONFIGURATION
SNMP COMMUNITY NAMES
SNMP TRAPS
CHASSIS ENVIRONMENTAL
PORT REDIRECT FUNCTION
802.1Q VLAN CONFIGURATION
Figure 5-8 Chassis Menu Screen
Chassis Menu Screen
RETURN
1960_99
5-15
