User Manual
Ascom d81 DECT Handset

11.9 Send Data with Bluetooth Barcode Reader

The handset can be configured to receive data from a Bluetooth barcode reader and then
send the data to another destination. When the handset receives data, it is automatically
transmitted to the destination and is not stored in the handset. A dialog window "Message
sent" is displayed.
For more information about configuration, see Configuration Manual, Ascom d81 DECT
Handset, TD 92674EN. See also
user manual for the Bluetooth barcode reader.
12

Operation Notice

12.1 Accessibility and Voice Quality

The base network is not always available. If you do not get in contact with your system,
contact your system administrator. For best voice quality, avoid positioning near computer,
radio or similar equipment.
Operating Area
You can only use the handset in the area that is covered by your system. Outside this area
you will loose contact with the system. The signal strength icon is low and "Searching" is
displayed.
Out of Range
When you leave the system's coverage area a short beep will sound and the text
"Searching" will appear in the display.
The out of range beep is repeated every minute for 30 minutes. The sound can be turned
off by long pressing,
NOTE: If handset restriction is enabled, it might not be possible to turn the sound off. See
the handset's Configuration Manual.
When re-entering the coverage area it can take a couple of minutes before the handset
automatically has registered into the system.
13

System Handling

13.1 Software Upgrade and Additional Features

Software and parameters in the handset can be upgraded by using the PDM/Device
Manager. Examples of additional features that can be downloaded/configured via PDM/
Device Manager:
18 June 2018 / Ver. K
13 System Handling
Pair/Connect Bluetooth Barcode Reader
, or .
TD 92644EN
on page 82, and
94
