Alternatively, the ongoing call can also be disconnected and the PTT call connected if the
following is fulfilled:
• The handset is configured to answer invitations automatically
• The user does not respond to the invitation within 10 seconds
• The invitation has higher priority than the ongoing call
If the user declines the invitation, the he/she can re-join the PTT later on, see
Group on page 57.
Accept Invitation Received as Message (PTT Advanced)
A PTT invitation received as a message is viewed the same way as an ordinary message.
The message can contain up to 1000 characters. See
Fire alert in
building A...
Accept
Figure 6. Incoming Invitation Received as a Message
1 Press "Accept".
The handset may accept the invitation automatically, start in inverted mute and
loudspeaking mode, depending on the configuration of the received invitation.
When the invitation is accepted, the following screen appears (see
The invitation can now be deleted or closed by clicking the soft key Delete or Close,
respectively. The call is not disconnected when clicking these soft keys. The soft key Call is
used for re-joining a group only, see
Fire alert in
building A...
Call
Figure 7. Accepted PTT Invitation
18 June 2018 / Ver. K
7 Menu Operation
12:34
Reject
12:34
Delete Close
Figure
7.1.8 Re-join a Group on page 57.
TD 92644EN
7.1.8 Re-join a
6.
Figure 7 on page 55).
