Ascom d81 DECT Handset
5 Select "Function".
6 Select function from list, and press "Back".
7 Select "Value" (only for some of the functions), and press "Select". Enter a value for
example a number. Press "Back".
8 Select "Control question", and press "Select". It is off by default.
If the control question is enabled, a Proceed? dialog window is displayed when
pressing the defined Hot key. Press "Yes" to proceed.
9 Press "Save"
7.7.3

Define Navigation Key

1 Enter the menu by pressing "Menu".
2 Select
3 Select "Navigation keys".
4 Select "Up", "Down", "Left", or "Right".
5 Select "Function".
6 Press "Select" to select function for the key.
7 Select function from list, and press "Back".
8 Select "Value" (only for some of the functions). Enter a value for example a number.
Press "Back".
9 Select "Control question".
It is disabled by default. If the control question is enabled, a Proceed? dialog window
is displayed when pressing the defined key. Press "Yes" to proceed.
10 Press "Save".

7.8 Settings

7.8.1

Sound and Alert Settings

Adjust the Ring Volume
NOTE: An intrinsically safe handset's ring volume is lower than a non-intrinsically safe
handset's ring volume due to current limitations.
1 Enter the menu by pressing "Menu".
2 Select
3 Select "Sound & Alerts.
4 Select "Volume".
5 Step with
the setting.
NOTE: If a handset restriction is enabled, it might not be possible to set the ring signal to
Silent. See the handset's Configuration Manual for more information.
18 June 2018 / Ver. K
7 Menu Operation
in the menu.
in the menu.
to increase the volume and with to decrease it. Press "Back" to save
TD 92644EN
72
