Ascom d81 DECT Handset
There are two desktop chargers available; one basic (DC3) that only charges the handset,
and one with advanced functionality (DC4) to download new software and to synchronize
parameters. The handset is fully operational while placed in the charger.
The charger is delivered with a plug-in power supply and is connected into an ordinary wall
socket. For more information, see the advanced charger's Installation and Operation
Manual.
IMPORTANT: When charging the EX classified handset, it is only permitted to use a
NOTE: Only use the charger within the temperature range of +5°C – +40°C.
2.2.2

Charging Rack

There are two charging racks (CR3):
• one used for charging several handsets, to synchronize parameters, and for software
download
• one used for charging several handsets only
IMPORTANT: If using the CR3 for charging EX classified handsets, it is only permitted to use
a charging rack marked with CR3-AxxB (rev. 2A) or CR3-AxxC on the label.
The built in power supply can charge up to six handsets.
See the Charging Rack's Installation and Operation Manual.
2.2.3

Battery Pack Charger

The Battery Pack Charger (CR4) is used for charging up to six spare batteries.
IMPORTANT: It is not permitted to charge EX classified batteries using the battery pack
See the battery pack charger's Installation Guide.
2.2.4

Clips

Tip: The handset can be used without a clip, see
The belt clips cannot be used if the handset is placed in a case. See
on page 22 for more information.
There are two belt clips available:
• Hinge-type clip
To prevent the handset from slipping out of for example pocket or belt, see
the Hinge-type Clip
• Swivel-type clip
To be able to rotate without slipping out from for example pocket or belt, see
the Swivel-type Clip
2.2.5

Security Cord

The security cord is 800 mm long. The security cord is attached directly to the handset.
18 June 2018 / Ver. K
2 Descriptions
charger marked with DC3-xxxB/rev. 1A (or higher rev.), DC4-xxxB/rev. 3A (or
higher rev.) on the label.
charger.
on page 100.
on page 100.
14.5 Attach Cover for No Clip
2.2.7 Leather Casing
TD 92644EN
on page 101.
14.3 Attach
14.4 Attach
21
