User Manual
Ascom d63 DECT Handset
Battery
The battery is a rechargeable Li-pol battery, placed under a battery cover. See
Replace the Battery
The battery is fully charged within four hours. See
The battery can be charged separately with a special battery charger. See
Spare Batteries
2.2

Chargers

2.2.1

DC3 Desktop Charger and DP1 Desktop Programmer

Figure 2. DC3 Desktop Charger and DP1 Desktop Programmer.
The DC3 Desktop Charger will only charge the handset, while the DP1 Desktop Programmer
will download new software and synchronize parameters. The handset is fully operational
while placed in the charger.
The DC3 Desktop Charger is delivered with a plug-in power supply and is connected into an
ordinary wall socket.
NOTE: Only use the charger within the temperature range of +5° C – +40° C.
2.2.2

CR3 Charging Rack

The CR3 Charging Rack is used for charging several handsets, to synchronize parameters,
and for software download.
The built in power supply can charge up to six handsets.
See the Installation and Operation Manual for CR3 Charging Rack.
2.2.3

Battery Pack Charger

The Battery pack charger is used for charging up to six spare batteries.
28 June 2016 / Ver. PA5
on page 84.
on page 84
15.1.2 Charge the Battery
15.1.3 Charge
TD 93119EN
15.1.4
on page 84.
6
