2. Fix a debugged servo to A02 and A03

.
Assemble the following components
For convenience to read,
A02 is displayed in green,
M2*10 Screw x1
and the color of all acrylic
sheets is subject to the
A03 x1
actual product.
A02 x1
Servo x1
M2 Nut x1
Effect diagram after assembling
