It is the pin interface for external power supply. Use 6-24V external power supply
to power the Adeept SmartHub development board.
【4】RESET：
Restarting the Adeept SmartHub development board.
【5】Switch：
When using Vin (6-24V) as an external power supply, Switch can control the OFF
and ON of the Adeept SmartHub development board.
【6】Micro USB：
It is used to connect the Micro USB interface of the computer to realize the serial
communication, uploading program and serial monitoring between the Adeept
SmartHub development board and the computer.
【7】Potentiometer button：
Potentiometer button has five buttons: A0, A1, A2, A3, and A6. By rotating these
buttons, you can control the movement of the robotic arm.
In the following courses, we will combine the application of various components to
further learn the practical application of the Adeept Arm Drive Board development
board.
