6.1.3 Turnplate and Rocker Arm Assembly

Servo debugging （
Lesson 5, then you don't need to adjust it anymore, please proceed to the next part
Connect five servos to the Adeept Arm Drive Board.
`
This is the No. 1
servo
If you have already adjusted the steering gear to 90 degrees according to
For convenience to read, only one
end of the servo power cable is
shown here.
Connect No. 1-5 servo, and increase from
No. 1-5 in the direction close to the oled
screen. Note that the direction of the Servo
interface should not be reversed
