12.Connect A05 with A08 and A11.
Assemble the following components
M3 Lock Nut x2
A08 x1
A11 x1
A05 x1
M3*12 Screw x2
Do not tighten between M3 Lock Nut and M3*12 Screw. Allow rotation between A05 and
A08, also A08 and A11.
Effect diagram after assembling
