Connect the 18650x2 Battery Holder to Adeept Arm Drive Board.
The anode (red wire) of the
18650x2 Battery
connects to the VCC interface.
The negative (black wire) is
connects to the GND interface.
And the switch is turned off.
Once the circuit is connected, load your 18650 battery into 18650x2 Battery Holder and turn
on the switch on the Adeept Arm Drive Board. At this point, the servo will automatically rotate to
the initial state, then turn off the power and remove each servo.
In the subsequent installation processes, before fixing the servo to the rocker arm with screws, do
not rotate the rotary shaft of the servo. Otherwise, you need to follow this step again to debug the
servo.
Holder
68
Switch
