Introduction
1.2

Box Content

Before beginning, verify that all of the following is in the box. If
anything is missing please report the discrepancy to your nearest
Rosslare Office.
One unit

Installation kit

1 drilling template (label/sticker)

 1 security spline key
1 security hex screw

4 mounting screws and wall plugs

1.3

Ancillary Equipment

The following ancillary equipment may be required to complete
your installation:
Electric Lock Strike Mechanism – fail safe (power to lock) or

fail secure (power to open).
Power supply with backup battery – 12 to 24 VDC (from a

regulated power supply) or 16 to 24 VAC (from a
transformer).
 Request to Exit (REX) Button (optional) – normally open type;
switch is closed when pressed.
12 AC-F/G4x Series Installation and Programming Manual
