Digital Power Meter Display, 5000-NG
Battery Life
1 Camera interface disabled from factory for security, user activation
required.

Physical and Environmental Specifications

Operating Temperature
Storage Temperature
Mechanical Shock
Vibration
Drop
Bench Handling
Humidity, Max
Altitude, Max
Dimensions, Nominal
Bare Unit
With optional protective
boot
Weight, Max
Housing
Connectors/Interfaces

Compliance

CE
RoHS
69
Minimum 8 Hours continuous usage (except 7022)
24 hour data logging (display in sleep mode) (except 7022)
-20 to +60 °C (-4 to +140 °F)
–20 to +80 °C (–4 to +176 °F)
60G half-sine shock pulse
Swept 5 to 100 Hz, all axis, 0.35mm
EN 61010-1: 1 m in most severe position
MIL-PRF-28800F, Class 2: 10 drops corners & faces
MIL-PRF-28800F, Class 2: 4 drops each face
95% maximum (non-condensing)
15,000 ft. (4,600 m)
8.78" x 5.95" x 0.77" (223 x 151 x 20 mm)
9.19" x 6.31" x 1.1" (233 x 160 x 28 mm)
1.3 lbs. (590g)
PC/ABS with rubber protective edge cover
Micro USB PC interface & charging,
Standard USB power sensor interface
Conforms to Radio Equipment Directive 2014/53/EU,
3.1(a) Health & Safety, 3.1(b) Electromagnetic
Compatibility & 3.2 Effective Use of Spectrum
Compliant to RoHS Directive 2011/65/EU Annex II and
amending Annex (EU)2015/863
