Sensor Displays and Menus
Figure 5
Power Meter Display
Item
Display Controls
1
Menu
Display Area/
2
Readings Menu
Sensor
Operations
3
Menu
Display Area
Readings Menu
Sensor measurements are displayed on the reading menu in a list format. The
top reading is enlarged to aid visibility and an analog bar meter provides visual
reference of the signal level.
Graphical Displays —
format by tapping the Display Controls Menu to display the graph options and
selecting a graph from the list. See Graph Displays for additional information.
Used to configure the sensor and choose the format
for displaying measurement data. See
Controls Menu" on page 14
Displays the numerical readings available/selected
device readings. The information on the readings
menu can also be displayed in table or graphical
format. See
"Display Area" on page 12
Used to load Presets, select modes, send device
commends, start Logging and share measurement
results. See
"Sensor Operations Menu" on page 23
for detailed description of the available options.
Any readings may be displayed in graphical or tabular
User Interface
"Display
.
.
12
