RF Line Connection

WARNING

Never attempt to connect or disconnect RF equipment from a

transmission line while RF power is applied. Leaking RF energy is a

potential health hazard.

1. Connect output of the transmitter to the input of the power sensor.

2. Connect output of the power sensor to the systems antenna or a load.

Figure 3

RF Power Measurement Setup

For a description of RF Power Meter Software displays and menus, see

"Sensor

Displays and Menus" on page 12
