Memory Expansion

There are two options for extending the internal memory of the 5000-NG. There
is a MicroSD slot and a USB port. While memory expansion is not required for
proper operation of the 5000-NG, it provides a easy way to transfer information
off of the power meter. Memory devices should be unmounted via software
before being physically removed, see

Eject Memory Device

This procedure should be performed to avoid corrupting the data stored on the
external memory device.
1. Long Press the Home Icon.
2. Tap Settings on the menu. See
Figure 17 Settings Menu
3. Type the password (5000ng) and tap confirm.
4. Tap Storage.
Figure 18 Unmount Storage Device
5. Scroll to SD Card or USB Storage
6. Tap the Unmount option.
7. Wait for unmount operation to complete.
8. Remove the storage device.
"Eject Memory Device" on page 32
.
Figure 17
User Interface
.
32
