Importing Logs into Excel
This procedure will display each group of results on one row with each
measurement and values grouped by columns.
1. Transfer the log files to a PC.
2. Open an Excel spreadsheet.
3. Select Data Tab.
4. Click From Text on the menu. The Import Text File dialog box will open.
5. Select All Files, in the drop down menu at the bottom of the dialog box. Log
files have the file extension .log.
6. Navigate to the folder containing the log file to import.
7. Select the file and click Import. This will open the Text Import Wizard.
8. On step 1, Select Delimited radio button, then click Next.
9. On step 2, select Comma and Other (add { ) as the delimiters, then click
Next.
10. On step 3, click finish.
Figure 13 Log File Open In Excel
Note: Columns have been removed in the example for simplicity.

Share Readings via Bluetooth

Readings may be transfered from the 5000-NG using the following steps.
1. Prepare destination PC or Android device to receive Bluetooth
2. Verify Bluetooth is on. If off, see
Services" on page 33
3. Tap the Sensor Operation Menu .
4. Select Share Readings.
5. Tap Bluetooth
6. Select the Bluetooth device from the list.
Figure 14 Share Readings
"Starting and Stopping Communication
.
