Transfer Files From The 5000-Ng To A Pc Via Usb Cable; Transfer Files From 5000-Ng To A Pc Using Bluetooth - BIRD Digital Power Meter Display Operation Manual

Transfer Files from the 5000-NG to a PC
Ensure 5000-NG is fully charged using the supplied adapter before connection
Due to the amperage required to charge the 5000-NG, charging from a PC
1. Connect USB cable between USB port on the 5000-NG and USB port on a
PC.
2. On the PC, open the device (TT800V) in Windows Explorer.
3. Files may be copied directly to or from the 5000-NG's internal storage and
connected a USB Drive or MicroSD card to the PC.
Note: Log files and session logs generated by the Bird RF Power Meter
Software are stored in the 5000-NG Internal storage in a folder titled
Bird RF Meter.
Figure 25 Windows Explorer Display

Transfer Files from 5000-NG to a PC using Bluetooth

Note: The PC and the 5000-NG must be paired prior to performing
Bluetooth file transfers.
Note: These instructions are for a Windows 10 PC with Bluetooth
capability, this process may be different on other operating systems.
Files may be transfered to a Windows 10 PC using the following steps:
Windows PC
1. Click on the Bluetooth icon on the PCs taskbar.
2. Select Receive a File.
CAUTION
to a PC for file transfers.
may damage that power source.
File Transfers and Updates
via USB Cable
38
