Preparing a UTREL30-WiFi for first use
UTREL30-WiFi User Guide
25
Selecting this option will retain the wireless and network parameters currently stored
inside the unit. This option is also applied if you do not click the WiFi settings tab during
the configuration process.
The unit needs to be connected to a new wireless network
If you need to change the SSID, or the unit is new, select the desired SSID from the list.
You can also type a new SSID directly if the wireless network for which the unit is set up is
not available where you complete the configuration.
Once you have selected the SSID, type the network password (often called the
"WiFi password").
You may need to advise your network administrator of the MAC address shown in this
screen, so it is allowed to connect to the network.
®
Factory-new units do not contain any settings. In this case, please use the
LogTag
Online Connection Wizard
to connect the device to your wireless network and to
®
LogTag
Online.
Finalizing the configuration
Click
Configure
to upload the configuration data to the UTREL30-WiFi.
When the configuration is complete, unplug the UTREL30-WiFi from the USB socket and
replace the protective seal.
If you wish to configure more UTREL30-WiFi units with the same configuration, insert the
next loggers into USB sockets, wait until they are ready for configuration and click
Repeat
Configure. Alternatively, you can use the
Profile
function to configure multiple units with
the same settings.
You can upload the configuration to a UTREL30-WiFi logger as often as required.
