Operation - Zeiss Axioskop 2 FS plus Manual

Axioskop 2 FS plus
Axioskop 2 FS
MOT

OPERATION

Contents
3 OPERATION ................................................................................................................... 3-3
3.1 Overview of operation and function controls.................................................................... 3-3
3.1.1 Operation and function controls of the Axioskop 2 FS plus, manual.................................. 3-4
3.1.2 Keypad for objective focusing of the Axioskop 2 FS
3.2 Switching on and basic settings ..................................................................................... 3-19
3.2.1 Axioskop 2 FS plus, manual ........................................................................................... 3-19
3.2.2 Axioskop 2 FS
3.3 Illumination and contrasting techniques ......................................................................... 3-20
3.3.1 Setting of transmitted-light brightfield according to KÖHLER .......................................... 3-20
3.3.2 Setting of transmitted-light darkfield ............................................................................. 3-23
3.3.3 Setting of transmitted-light phase contrast..................................................................... 3-25
3.3.4 Setting of transmitted-light differential interference contrast (DIC).................................. 3-27
3.3.5 Setting of epi-fluorescence ............................................................................................ 3-30
3.4 Documentation ............................................................................................................. 3-32
3.4.1 Attachment of photomicrography equipment ................................................................ 3-32
3.4.2 Attachment of videomicroscopy equipment ................................................................... 3-35
3.4.3 Attachment of adapter for digital compact cameras ....................................................... 3-36
3.5 Quantitative microscopy ................................................................................................ 3-37
3.5.1 Measurement of lengths................................................................................................ 3-37
3.5.2 Height measurement ..................................................................................................... 3-38
B 40-076 e 02/01
OPERATION
Contents
........................................................................................................ 3-19
MOT
(single-hand control)................. 3-13
MOT
Carl Zeiss
3-1
