Carl Zeiss

1.8

Technical Data

Dimensions (width x depth x height)

Axioskop 2 FS plus / FS

Weight

Axioskop 2 FS plus .............................................................................................................approx. 18 kg

Axioskop 2 FS

.............................................................................................................approx. 18 kg

MOT

Ambient conditions

Storage and transport (in packaging)

Permissible ambient temperature........................................................................................-10 to +60 ° C

Permissible relative humidity ..............................................................................20 % to 85 % at +35 ° C

Atmospheric pressure..............................................................................................800 hPa to 1060 hPa

Operation

Permissible ambient temperature.......................................................................................+10 to +45 ° C

Permissible relative humidity ..............................................................................20 % to 85 % at +35 ° C

Altitude ..............................................................................................................................max. 2000 m

Atmospheric pressure..............................................................................................800 hPa to 1060 hPa

Pollution degree ....................................................................................................................................2

Operating data

Operation ...........................................................................................................................closed rooms

Protection class ...................................................................................................................................... I

Enclosure protection........................................................................................................................ IP 20

Electrical safety ................................................................ in compliance with DIN EN 61010 (IEC 1010-1)

Overvoltage category ............................................................................................................................ II

Radio interference suppression .......................................................in accordance with EN 55011, Class B

Insensitivity to noise ................................................................................ in accordance with EN 50082-2

Line frequency ......................................................................................................................50 to 60 Hz

1-16

INSTRUMENT DESCRIPTION

with phototube and HAL 100..............approx. 280 mm x 600 mm x 475 mm

MOT

with phototube and HBO 103 .............approx. 280 mm x 733 mm x 475 mm

MOT
