Zeiss Axioskop 2 FS plus Manual page 23

Axioskop 2 FS plus
Axioskop 2 FS
MOT
Key to Fig. 1-2:
1 Stand
2 Eyepiece
3 Binocular ergotube 6-25° /23
4 HBO 100 W transformer
5 HBO 103 illuminator
6 HAL 12 V 100 W halogen illuminator
7 Separate 12 V DC 100 W power unit
8 FL filter slider
9 DIC slider
10 Objective
11 Control unit
12 Keypad
13 Dust cover
14 DIC prism
15 Achromatic-aplanatic universal condenser 0.9 H D DIC
16 Filter mount
17 Mechanical stage 75x50/240° R
18 Universal mounting frame
19 Reflector module FL P&C
20 Analyzer module D
B 40-076 e 02/01
INSTRUMENT DESCRIPTION
Axioskop 2 FS microscope configurations ...
MOT
Carl Zeiss
1-9
