Opto-mechanical data
Stand with manual objective focusing
coarse drive ..........................................................................................................6 mm / rotation
fine drive ................................................................................ 0.1 mm / rotation; 1 µm increments
lifting range ............................................................................................................... max. 11 mm
Achromatic-aplanatic universal condenser 0.9 with
swing-in front lens 0.9
for objective magnifications M
for objective magnifications M
brightfield insert with turret disk with 5 or 7 positions;
.................................................................................................................for brightfield, darkfield
.............................................................................................................. for phase contrast 1, 2, 3
............................................................................................................ for DIC I, II, III (changeable)
Objective change .............................................................manually via 2-position slider H DIC, W 0.8" FS
Change of technique modules.......................................................manually via 5-position reflector turret
Axioskop 2 FS
MOT
Stand with objective focusing ................................................................................................. motorized
lifting range ........................................................................................................................11 mm
focusing............................................................................................ via motor control and keypad
focusing speed................................................................................................................... variable
end switch for working area.......................................................................can be set electronically
activation of stored focus positions..................................................up to 4 positions can be stored
defined deactivation and activation of the latest work position ........................... via Home function
focusing in defined steps.................................................. increments available from 0.1 to 499 µm
1-18
INSTRUMENT DESCRIPTION
Technical data
< 10x ....................................swing out condenser front lens 0.9
obj.
≥ 10x ..................................... swing in condenser front lens 0.9
obj.
Axioskop 2 FS plus
Axioskop 2 FS
MOT
