Zeiss Axioskop 2 FS plus Manual page 19

Axioskop 2 FS plus
Axioskop 2 FS
MOT
Key to Fig. 1-1:
1 Stand
2 Eyepiece
3 Binocular tube 30° /23
4 HBO 100 W transformer
5 HBO 103 illuminator
6 HAL 12 V 100 W halogen lamp
7 Separate 12 V DC 100 W power unit
8 FL filter slider
9 DIC slider
10 Objective
11 Dust cover
12 DIC prism
13 Achromatic-aplanatic universal condenser 0.9 H D DIC
14 Filter mount
15 Mechanical stage 75x50/240° R
16 Universal mounting frame
17 Reflector module FL P&C
18 Analyzer module D
