Zeiss Axioskop 2 FS plus Manual page 38

Carl Zeiss
Fig. 2-2 Remove transport locking device
After removal of the safety screw, the microscope must not be held at the objective slider to
lift it for a change of position, since this will damage the mechanical components of the
focusing drive.
For the Axioskop 2 FS plus
the removal of a further transport lock.
2-6
START-UP
Initial start-up
2.1.2
To exclude damage to the precision objective
focusing
Axioskop 2 FS plus / FS
equipped with two safety screws and a carrying
handle. When the microscope has been set up,
these items must be removed.
• Remove both safety screws (2-2/1) using a
SW 3 ball-headed screwdriver.
• Remove all adhesive tapes, including those at
the drive knobs.
• Use SW 3 ball-headed screwdriver to loosen
both fixation screws (2-1/1) of the carrying
handle bases (2-1/3) and remove the carrying
handle (2-1/2) with bases from the stand.
, please observe the note at the rear of the stand concerning
MOT
Axioskop 2 FS plus
Axioskop 2 FS
Remove transport
carrying handle
drive during transport,
microscopes
MOT
B 40-076 e
MOT
lock and
the
are
02/01
