CE Radio Information
Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+. EM7430 specifications.
Bands
Band 1
Band 8
B.2 WIFI specifications
This product is supplied with internal antennas.
Technology: WLAN 802.11a/b/g/n/ac.
Frequency Range
Number of Channels
Type of modulation
38
Frequencies
Tx: 1920–1980 MHz
Rx: 2110–2170 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
802.11b/g/n-HT20: 2412 ~ 2472MHz;
802.11n-HT40: 2422 ~ 2462MHz;
802.11a /n-HT20/ac-VHT20: 5180~5240 MHz, 5260~5320 MHz, 5500~5700 MHz;
802.11n-HT40/ac-VHT40: 5190~5230 MHz, 5270~5310 MHz, 5510~5670 MHz;
802.11ac-VHT80: 5210 MHz, 5290 MHz, 5530 MHz, 5610 MHz.
802.11a/n-HT20/ac-VHT20: 19
802.11n-HT40/ac-VHT40: 9
802.11ac-VHT80: 4
2.4 GHz:
802.11b: DSSS
802.11g/n: OFDM.
5.0 GHz:
802.11a/n/ac: OFDM.
Conducted Transmit Power
+23 dBm ± 1 dB
+23 dBm ± 1 dB
