3 Components and Power Supply
E
F
G
H
I
J
K
L
M
N
8
- WAN Connections on page 14
- WAN Base-T Connector on page 29
- WAN Base-T Interface on page 31
Eth WAN-1 SFP.
For more information about the SFP interface, refer to:
- WAN Connections on page 14
- WAN SFP Connector on page 29
- WAN SFP Interface on page 31
Eth WAN-2 Base-T. WAN Gigabit Ethernet.
For more information about the WAN interface, refer to:
- WAN Connections on page 14
- WAN Base-T Connector on page 29
- WAN Base-T Interface on page 31
Eth WAN-2 SFP.
For more information about the SFP interface, refer to:
- WAN Connections on page 14
- WAN SFP Connector on page 29
- WAN SFP Interface on page 31
Aux. Provides access to the M8-Smart local console for configuration and monit-
oring purposes.
For more information about the Aux connector, refer to:
- Connecting for Configuration
- Configuration Connector on page 30
- Configuration Interface on page 35
SIM Card 1-2. Slot where you can insert the SIM cards for the G modules.
Refer to Installing the SIM card
ation.
On/Off switch.
Power source connection (PSU).
Refer to Power Source on page 12 for more information about Power connection
and Power Supply on page 35 for power specifications applicable to the M8-Smart
device.
LED S (Status). Refer to LEDs
LED PWR (Power). Refer to
Functional earthing. Usually disconnected.
on page 17
on page 18 for more information about SIM install-
on page 5 for more information.
LEDs on page 5 for more information.
