Teldat M8-Smart Installation Manual page 11

3 Components and Power Supply
WAN-1
WAN-2
LAN Switch
WLAN-1
(Depending on
the model)
WLAN-2
(Depending on
the model)
Cell
(Depending on
the model)
6
Base-T / SFP
Base-T / SFP
LAN switch interface activity
Access Point 2.4 GHz radio
Access Point 5 GHz radio
Status
RSSI.
Coverage indication
Amber (blink) -> Default configuration.
Off -> No link or not used.
Green -> Link (1G). Blinking: traffic activity.
Amber -> Link (<1G). Blinking: traffic activity.
Red -> Error. Interface failure.
Off -> No link or not Used.
Green -> Link (1G). Blinking: traffic activity.
Amber -> Link (<1G). Blinking: traffic activity.
Red -> Error. Interface failure.
Green -> connected (all connected ports at 1G). Blinking: connec-
tion data activity.
Amber -> connected (at least one port at <1G). Blinking: connec-
tion data activity.
Red -> Disconnected.
Off -> Interface off.
Off -> Radio module and/or SSIDs inactive.
Red -> No connection or disabled (shutdown).
Amber -> Enabled but no associated STAs.
Green -> Connected. Blinking: connection data activity.
Off -> Radio module and/or SSIDs inactive.
Red -> No connection or disabled (shutdown).
Amber -> Enabled but no associated STAs.
Green -> Connected. Blinking: connection data activity.
Off -> System stopped.
Red -> Interface is unavailable because it is installing, disabled
(shutdown) or due to auto-test failure.
Amber -> Idle:
• Rapid blinking. It has not registered in the network or the quality
is insufficient.
• Slow blinking. GSM connection (GPRS).
• Steady. WCDMA (UMTS / HSDPA) connection.
Green -> Connected. Blinking: connection data activity.
Off -> No coverage.
1-to-4 LEDs -> Level of coverage.
