Teldat S.A.
GNSS
CONNECTOR
SIM Slots
ANTENNA
A.5.6 GPS interface
STANDARDS
GNSS
SATELLITE CHANNELS
CONNECTOR
ANTENNA
M8-Smart
• FDD. 300Mbps/50Mbps
• TDD: 222Mbps/26Mbps
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
GPS/GLONASS/BeiDou/Galileo/QZSS
Three SMA connectors.
2 Mini-SIM (2FF) ISO/IEC 7810:2003, ID-000 (1.8V / 3V)
Devices equipped with this interface are shipped with two multiband swivel-mount
dipole antennas.
NMEA.
• GPS (L1, 1559-1610 MHz)
• GLONASS (G1, 1559-1610 MHz)
• BeiDou (B1, 1559-1610 MHz)
• Galileo (E1, 1559-1610 MHz)
• 16 GPS
• 14 GLONASS
• 16 BeiDou
• 12 Galileo
Simultaneous tracking.
SMA female.
Active and Passive.
Technical Information
