Maintenance - AJAX KeyPad Plus User Manual

2. Check the convenience for password entry using Tag or Pass to manage security
modes. If it is inconvenient to manage the security at the selected location, relocate the
keypad.
3. Remove the keypad from the SmartBracket mounting plate.
4. Attach the SmartBracket mounting plate to the surface using the bundled screws.
When attaching, use at least two xing points. Be sure to x the perforated corner on
the SmartBracket plate so that the tamper responds to a detachment attempt.
5. Slide KeyPad Plus onto the mounting plate and tighten the mounting screw at the
bottom of the body. The screw is needed for more reliable fastening and protection of
the keypad from quick dismantling.
6. As soon as the keypad is xed on the SmartBracket, it shall blink once with LED X —
this is a signal that the tamper has been triggered. If the LED does not blink after
installation on SmartBracket, check the tamper status in the Ajax app, and then make
sure the plate is rmly attached.

Maintenance
