Outside the premises (outdoors).
Nearby or inside any metal objects or mirrors causing attenuation and screening of the
signal.
In places with high radio interference level.
Close to radio interference sources: less than 1 meter from the router and power cables.
Inside any premises with the temperature and humidity beyond the range of permissible
limits.

Maintenance

Check the operational capability of the Ajax security system on a regular basis. Clean the hub
body from dust, spider webs and other contaminants as they appear. Use soft dry napkin
suitable for equipment maintenance.
Do not use any substances containing alcohol, acetone, gasoline and other active solvents for
cleaning the hub.
How to replace hub battery

The package includes

1. Hub 2 Plus
2. SmartBracket mounting panel
3. Power cable
4. Ethernet cable
5. Installation kit
6. Starter pack — not available in all countries
7. Quick Start Guide

Technical Speci cations

Classi cation
Support of detectors with photo veri cation of alarms
Number of connected devices
Number of connected ReX
Number of security groups
Number of users
Video surveillance
Number of rooms
Number of scenarios
Central Monitoring Station communication protocols
Power supply
Built-in back-up battery
Energy consumption from the grid
Tamper proof
Operating frequency band
RF output power
Radio signal range
Communication channels
Operating temperature range
Operating humidity
Size
Weight
Security system control panel with Ethernet, Wi-Fi, and
dual SIM card support
Available
Up to 200
Up to 5
Up to 25
Up to 200
Up to 100 cameras or DVRs
Up to 50
Up to 64
(Reactions by arming and disarming are not included in
the overall limit of the hub's scenarios)
Contact ID, SIA (DC-09)
CMS software supporting visual alarms
veri cation
110-240 V with pre-installed battery
6V PSU
6 V with alternative power supply
Energy consumption from the 110-240 V grid — 10 W
Li-Ion 3 А·h
Ensures up to 15 hours of operation when using SIM card
only
Up to 10 W
Available, tamper
868.0–868.6 MHz or 868.7–869.2 MHz, depending on the
sales region
10.4 mW (max 25 mW)
Up to 2000 m
2 SIM cards
2G (GSM900/DCS1800 (B3/B8))
3G (WCDMA 850/900/2100 (B1/B5/B8))
LTE (FDD B1/B3/B5/B7/B8/B20/B28)
Wi-Fi (802.11 b/g/n)
Ethernet
From –10°C to +40°C
Up to 75%
163 × 163 × 36 mm
367 g
