FireProtect 2 AC (Heat/Smoke/CO) Jeweller

user manual

Updated April 3, 2024

FireProtect 2 AC (Heat/Smoke/CO) Jeweller is a wireless mains-powered re

detector with a backup battery and a built-in siren. Designed for indoor

installation. Detects smoke, temperature rise, and dangerous CO (carbon

monoxide) level.

The re detector is also available without an external power supply in two

modi cations:

FireProtect 2 SB (Heat/Smoke/CO)

with sealed batteries that last

10 years, and

FireProtect 2 RB (Heat/Smoke/CO)

with replaceable batteries that

last up to 7 years.

The detector operates as part of the Ajax system, communicating with the hub

via the

Jeweller

secure radio protocol. The hub communication range is up to

1,700 m without obstacles.

Buy FireProtect 2 AC (Heat/Smoke/CO)

Table of Contents

Need help?

Do you have a question about the FireProtect 2 AC and is the answer not in the manual?

Questions and answers

Summary of Contents for AJAX FireProtect 2 AC

Page 1 10 years, and FireProtect 2 RB (Heat/Smoke/CO) with replaceable batteries that last up to 7 years. The detector operates as part of the Ajax system, communicating with the hub via the Jeweller secure radio protocol. The hub communication range is up to 1,700 m without obstacles.
Page 2: Functional Elements
Versions of the detector with other sensor combinations are also available. All Ajax re detectors are available here CableTrunk is available for the FireProtect 2 AC detectors for convenient cable routing. It allows you to neatly route the re detector’s power cable from the standard cable trunking.
Page 3 The system identi es this event as a malfunction, and the detector reacts with an audible signal. Users and the security company receive a malfunction noti cation. Compatible hubs and range extenders The detector is compatible only with Ajax hubs with the rmware OS Malevich 2.18 and higher.
Page 4: Operating Principle
Operating principle 00:00 00:12 FireProtect 2 AC (Heat/Smoke/CO) Jeweller is a wireless re detector designed for indoor installation. It can operate from a 110-240 V~, 50/60 Hz power supply, and has a built-in backup battery. The Battery Life Optimization feature must be enabled to ensure such a lifetime for a...
Page 5: Smoke Sensor
SmartBracket mounting panel. The detector responds with LED indication. The users receive noti cations via Ajax apps while the monitoring station processes the alarm. The second tamper noti es on the removal of the smoke chamber lid, which is located under the front panel of the detector.
Page 6 Heat sensor Two built-in class A1R thermistors detect a rapid rise and exceeding the temperature threshold in FireProtect 2. Such thermistors notify of alarms when a rapid temperature rise or static temperature is detected in the range of +54°C to +65°C.
Page 7 In case of a fault, low battery level, or end of life, it mutes the sound and LED indication for 12 hours. Use any remote silencing feature (e.g., via Ajax app) only in the line of sight of the CO sensor.
Page 8: Adding To The System
When an alarm is received, the operator at the security company’s CMS knows what happened and precisely where to dispatch a rapid response team. The addressability of Ajax devices allows sending events to PRO Desktop or the CMS, including the device type, its name, security group, and virtual room. Note that the list of transmitted parameters may vary depending on the CMS type and its communication protocol.
Page 9 3. Ensure that the hub is switched on and connected to the internet via Ethernet, Wi-Fi and/or mobile network. 4. Ensure that the hub is disarmed and does not start updating by checking its status in the Ajax app. PRO or a user with admin rights can pair the device with the hub.
Page 10 The hub and the device operating at different radio frequencies are incompatible. The device frequency range may vary by region. We recommend purchasing and using Ajax devices in the same region. You can verify the range of operating radio frequencies with the ...
Page 11 Autonomous operation mode FireProtect 2 detectors can be used autonomously without connecting to an Ajax hub. In this case, the detector noti es of re, smoke, or dangerous CO level with only a built-in siren and LED indication . Users don’t receive noti cations on...
Page 12 CO level drops below 50 ppm. You can also mute the alarm by pressing the Test/Mute button or in the Ajax app. The alarm The red LED ashes 3 The siren beeps in Alarm by dangerous cannot be muted if...
Page 13 Tamper alarm. The detector is The yellow LED lights removed from the up for 1 second. SmartBracket mounting panel. The detector is The green LED lights installed on the Turns on when the up for 1 second. SmartBracket tamper is triggered. mounting panel.
Page 14 Jeweller Signal Strength Test mode. All malfunctions are displayed in the states detector Ajax apps. Fields with malfunctions are The siren beeps in The yellow LED highlighted in red. time with the LED ashes 2 times in a Malfunction detected.
Page 15 Then ashes 3 more Performing a self-test. the Ajax app. Then it makes 3 times but slower longer beeps during during the CO sensor In CO-free versions, the CO sensor test.
Page 16 when the network of detectors is formed. Learn more The indication turns on when the detector chooses its role after switching to the pairing mode without The detector becomes The green LED ashes the hub. It turns off a slave after switching every 2 seconds.
Page 17: Functionality Testing
The test allows you to check the status of the detector’s sensors. You can run it in two ways: by pressing the Test/Mute button of the detector and in Ajax apps. If the detector is in an alarm state, the self-test is not available.
Page 18 How to test FireProtect 2 Testing at the installation spot An Ajax system provides several tests to select the correct installation place of devices. Jeweller Signal Strength Test is available for FireProtect 2. The test determines the strength and stability of the signal at the intended location of the device.
Page 19 Jeweller (or Jeweller/Fibra) menu in the hub settings. Icons The icons in the app display some FireProtect 2 states. To access them: 1. Sign in to the Ajax app 2. Select a hub. 3. Go to the Devices tab.
Page 20 The detector has tamper triggering events deactivated. Learn more The detector was not transferred to the new hub. Learn more States The states include information about the device and its operating parameters. You can nd the states of FireProtect 2 in Ajax apps:...
Page 21 4. Select FireProtect 2 from the list. Ajax apps display three FireProtect 2 temperature parameters. The rst one shows the air temperature in the room where the detector is installed. The other two (Temperature Threshold Exceeded and Rapid Temperature Rise) show whether re-related temperature changes are detected.
Page 22 OK — the backup battery has su cient charge. Normal state. Battery low — the backup battery is discharged. When the battery is discharged, users and the security company monitoring station receive a noti cation. After the low battery noti cation, the detector is able to operate for another month under normal conditions.
Page 23 Learn more Alarm state if temperature threshold is exceeded: No — normal state, the detector does not detect temperature threshold exceeding. Alarm — the detector has detected a Temperature Threshold Exceeded temperature threshold exceeding. If temperature threshold exceeding is detected, the text eld highlights red.
Page 24 The FireProtect 2 loop (zone) number. Events Device No. are sent to the CMS with this number. Settings To change FireProtect 2 settings, in the Ajax app: 1. Go to the Devices tab. 2. Select FireProtect 2 from the list.
Page 25 Rapid Temperature Rise Alarm an alarm if the device detects a rapid rise in temperature. Alert with a siren Ajax sirens When this option is enabled, the connected to the system are activated when the If temperature threshold exceeded detector detects a temperature threshold exceeding.
Page 26 Unpairs FireProtect 2 from the hub and deletes Unpair Device its settings. Selecting an installation place The detector is designed for indoor installation only. The coverage area of one FireProtect 2 AC (Heat/Smoke/CO) is 50 to 60 m², depending on the type of premises.
Page 27 The detector should be installed in every room. The detector is placed in the center of the ceiling at a distance of 30 cm from light xtures, chandeliers, or any other decorative objects that may interfere with alarm detection. If there are beams on the ceiling protruding 30 cm or more, the detector must be installed between every two beams.
Page 28: Signal Strength
Obstacles that affect the radio signal: walls, inter oor ceilings, big objects in the room. Consider the placement recommendations when designing your Ajax system for the object. The security system must be designed and installed by specialists. The list of recommended Ajax partners is...
Page 29: Installation
In places with low or unstable Jeweller signal strength. This can result in connection loss. Inside premises with temperature and humidity outside the permissible limits . This could damage the detector. In places with fast air circulation. For example, near fans, vents, open windows, or doors.
Page 30 Users and the security company receive a malfunction noti cation. During installation and operation of the Ajax security system, adhere to the rules and requirements of regulatory legal acts on electrical safety. Do not disassemble the device while it is energized or use it with a damaged power cable.
Page 31 20 cm can signi cantly improve the signal strength. If there is still low or unstable signal after the relocation, use a radio signal range extender 4. Remove the detector from the mounting panel. Remove SmartBracket from the surface. 5. Remove the protective cover from the mounting panel. To do this, turn the protective cover counterclockwise as shown below.
Page 32 10. Attach the SmartBracket panel with the bundled screws using all xation points. When using other fasteners, make sure they do not damage or deform the mounting panel. 11. Place the detector on the SmartBracket mounting panel. 12. Adjust the position of the detector if necessary. 13.
Page 33 NEVER IGNORE THE ALARM! Always assume the alarm is real, and evacuate from the premises immediately, even if you have doubts about the cause of the alarm signal. 1. Don’t open doors if you feel heat or smoke behind them. Check other exits and use an alternative escape route.
Page 34 If the alarm was silenced by the Test/Mute button (for CO level under 300 ppm), check the CO level at the Ajax app. If it is safe to enter the premises, press the Test/Mute button again to check the CO level.
Page 35 Engines of cars, generators, etc., are left running in con ned spaces (for example, a garage). Incorrectly or poorly installed fuel-burning appliances. Blocked or damaged vents or chimneys/ ues. The tightness of rooms where appliances for burning fuel or replaces are installed.
Page 36 Numerous cases of carbon monoxide poisoning show that children and household pets are affected rst. Malfunctions When a malfunction is detected, the Ajax app displays a malfunction counter on the device icon. All malfunctions are indicated in the device’s states. Fields with malfunctions will be highlighted in red.
Page 37: Maintenance
LED indication. FireProtect 2 devices connected to the Ajax hubs generally do not require routine testing. All connected devices are constantly monitored for possible faults, low backup battery, and EOL signals.
Page 38 Avoid the situations listed in the tables below. They may affect the reliability of the CO sensor in the short or long term. Situations that must be avoided Situation Possible consequences Contamination by alkaline Signi cant changes to the sensor characteristics when the sensor is metals contaminated by alkaline metals, especially salt water spray.
Page 39: Technical Speci Cations
Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after the date of purchase. If you encounter any issues with the device’s functionality, we recommend contacting Ajax Technical Support rst. In most cases, technical issues can be resolved remotely. Warranty obligations...
