Only a user or PRO with full administrator rights can add a device to the hub.
To connect KeyPad Plus
1. Open the Ajax app. If your account has access to multiple hubs, select the one to which
you want to connect KeyPad Plus.
2. Go to the Devices
3. Name the keypad, scan or enter the QR code (located on the package and under the
SmartBracket mount), and select a room.
4. Click Add; the countdown will begin.
5. Turn on the keypad by holding the power button for 3 seconds. Once connected,
KeyPad Plus will appear in the hub device list in the app. To connect, locate the keypad
at the same protected facility as the system (within the coverage area of the hub radio
network range). If the connection fails, try again in 10 seconds.
The keypad only works with one hub. When connected to a new hub, the device stops sending
commands to the old hub. Once added to a new hub, KeyPad Plus is not removed from the device list
of the old hub. This must be done manually through the Ajax app.
KeyPad Plus turns off automatically 6 seconds after being turned on if the keypad fails to
connect to the hub. Therefore, you do not need to turn off the device to retry the
connection.
Updating the statuses of devices in the list depends on the Jeweller settings; the default
value is 36 seconds.
Icons
The icons represent some of KeyPad Plus states. You can see them in the Devices
in the Ajax app.
Icon
Jeweller signal strength — Displays the signal strength between the hub or
KeyPad Plus
Battery charge level of KeyPad Plus
KeyPad Plus works via a ReX radio signal range extender
menu and click Add Device.
Value
tab
range extender
and
