Bedienungsanleitung für Button S Jeweler
Button S Jeweler ist ein kabelloser Panikknopf mit Schutz gegen
versehentliches Drücken und zusätzlichen Modi: zur Steuerung von
Automatisierungsgeräten und zum Stummschalten von Feuermeldern.
Button S arbeitet in einem Ajax-System und ist über das geschützte
Protokoll mit dem Hub
Hindernisse beträgt bis zu 1.300 Meter.
Diese Produktlinie wird für Projekte entwickelt. Nur akkreditierte Ajax Systems-Partner
können Superior-Produkte installieren und verwalten.
Die Produktlinien Superior, Fibra und Baseline sind untereinander kompatibel. Dies
eröffnet zahlreiche Möglichkeiten für den Aufbau beliebig kon gurierter Systeme.
Funktionselemente
Aktualisiert4. Juli 2023
verbunden . Die Kommunikationsreichweite ohne
Jeweler-

Advertisement

loading
Need help?

Need help?

Do you have a question about the Button S Jeweller and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX Button S Jeweller

Summary of Contents for AJAX Button S Jeweller

  • Page 1 Button S Jeweler ist ein kabelloser Panikknopf mit Schutz gegen versehentliches Drücken und zusätzlichen Modi: zur Steuerung von Automatisierungsgeräten und zum Stummschalten von Feuermeldern. Button S arbeitet in einem Ajax-System und ist über das geschützte Jeweler- Protokoll mit dem Hub verbunden .
  • Page 2 1. Alarmknopf. 2. Signallampen. 3. Knopfbefestigungsloch. Kompatible Hubs und Range Extender Für den Betrieb des Detektors ist ein Ajax-Hub mit der Firmware OS Malevich 2.16 und höher erforderlich. Hubs Funksignal-Reichweitenverlängerer Hub Plus Hub 2 (2G) ReX 2 Hub 2 (4G)
  • Page 3 00:00 00:12 Button S Jeweller is a wireless panic button that operates in one of three modes: Panic, Control, Mute Fire Alarm. When the button is pressed, it transmits an alarm to users, as well as to the security company’s CMS. In...
  • Page 4 Note that in Panic mode, pressing the Button S will raise an alarm regardless of the system security mode. If Button S is pressed, an alarm can also run a scenario in the Ajax system...
  • Page 5 Socket To bind an automation device action to a long or short press of Button S: 1. Open the Ajax app and go to the Devices tab. 2. Select Button S in the list of devices and go to settings by clicking the gear icon 3.
  • Page 6 The hub and the device operating at different radio frequencies are incompatible. The radio-frequency range of the device may vary by region. We recommend purchasing and using Ajax devices in the same region. You can check the range of operating radio frequencies with the...
  • Page 7 ), you will be noti ed when you try to add a new one. The button connected to the hub will appear in the list of hub devices in the Ajax app. Button S works with one hub. When connected to a new hub, the button stops...
  • Page 8 This must be done through the Ajax app. Malfunctions When a malfunction is detected, the Ajax app displays a malfunction counter on the device icon. All malfunctions are shown in the button states. Fields with malfunctions will be highlighted in red.
  • Page 9 Button S is deactivated for a time the armed mode is active. Learn more States The states include information about the device and its operating parameters. The states of Button S can be found in Ajax apps: 1. Sign in to the Ajax app 2. Select the hub.
  • Page 10 (except for the Hub model) with rmware version OS Malevich 2.17 or higher. How battery charge is displayed in Ajax apps How to replace a battery of the button Displays the operating mode of the button. Three modes are available: Panic.
  • Page 11 Device No. Number of the device loop (zone). Settings To change Button S settings in the PRO Ajax apps: 1. Go to the Devices tab. 2. Select Button S from the list. 3. Go to Settings by clicking on the gear icon 4.
  • Page 12 Panic — sends an alarm when pressed. Control — controls automation devices by short or long (3 sec) pressing. Operating mode Mute Fire Alarm — when pressed, mutes the alarm of Ajax re detectors. The option is Interconnected Fire available if Alarm feature is enabled.
  • Page 13 0.5 seconds between the presses. If the toggle is enabled, pressing a panic button Ajax sirens activates connected to the Alert with a siren if button is pressed system. Button S activates all sirens, regardless of the groups they are in.
  • Page 14 User Guide Opens Button S user manual. Allows a user to deactivate the device without deleting it from the system. Once deactivated, the device will no longer execute system commands and participate in Permanent Deactivation automation scenarios. Additionally, the panic button of a deactivated device will be disabled.
  • Page 15 The button status is indicated with red or green LED indicators. Category Indication Event The button is not registered in Green LEDs ash 6 times any system Linking to system Lights up green for a few Adding a button to the system seconds Command is delivered to Lights up green brie y...
  • Page 16 To install the button in the holder: 1. Choose a location to install the holder. 2. Press the button to test whether the commands can reach the hub. If not, select another location or use a radio signal range extender When connecting Button S via radio signal range extender, note that Button S does not automatically switch between the radio networks of the radio signal extender and the hub.
  • Page 17 When the battery has run down, the user will receive a noti cation in the Ajax app, and the LED indicator will smoothly light up red and go out each time the button is pressed.
  • Page 18 Warranty obligations User agreement Contact Technical Support: e-mail Telegram Manufactured by “AS Manufacturing” LLC Subscribe to the newsletter about safe life. No spam Email Subscribe...
