StreetSiren DoubleDeck User Manual
StreetSiren DoubleDeck is a wireless outdoor siren with mount for the branded
faceplate. Equipped with a LED frame and piezoelectric alarm indicator
producing sound volume up to 113 dB, StreetSiren can operate up to 5 years
from pre-installed batteries. It can also be powered from an external 12 V power
supply.
StreetSiren DoubleDeck communicates with the hub via the secured Jeweller
radio protocol. The communication range is up to 1,500 meters provided there
are no obstacles.
The siren only works as part of the Ajax security system. Integration with third-party
systems and connection to
The siren is set up via
system noti es users of all events with push noti cations, SMS, and calls (if
activated).
Updated November 25, 2020
ocBridge Plus
Ajax apps
for iOS, Android, macOS, and Windows. The
or
uartBridge
are not supported.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AJAX StreetSiren DoubleDeck
Summary of Contents for AJAX StreetSiren DoubleDeck
- Page 1 StreetSiren DoubleDeck communicates with the hub via the secured Jeweller radio protocol. The communication range is up to 1,500 meters provided there are no obstacles. The siren only works as part of the Ajax security system. Integration with third-party systems and connection to ocBridge Plus uartBridge are not supported.
-
Page 2: Functional Elements
Buy street siren StreetSiren DoubleDeck Buy branded faceplate for StreetSiren DoubleDeck The Ajax security system can be connected to a central monitoring station (CMS) of the security company. A list of security companies is available on the website Functional elements 1. -
Page 3: Operating Principle
Operating principle StreetSiren DoubleDeck performs two tasks: 1. Informs about the alarm. The device responds to triggering of the tamper and security system alarms in less than a second, including a siren and LED backlight, which scares off intruders and attracts the attention of neighbors. - Page 4 2. Make sure that the hub is on and has Internet access. The status of the Internet connection is available in the Ajax app and is also indicated by the color of the hub’s logo (lights white or green).
- Page 5 The default value is 36 seconds. Up to 10 sirens can be connected to one hub. States of StreetSitren DoubleDeck Icons Icons display some of the StreetSiren DoubleDeck states. You can view them in Ajax app , in the Devices menu Icon...
- Page 6 We recommend installing the siren in places with the signal strength of 2-3 bars Connection status between the hub and StreetSiren DoubleDeck: Online — the siren is connected to the hub Connection O ine — the siren is not connected to the Battery level of the device.
- Page 7 Temporary Deactivation noti cations about triggering of the device tamper button are disabled StreetSiren DoubleDeck rmware version. It is Firmware not possible to change the rmware StreetSiren DoubleDeck ID/serial number. Also located on the device packing box and under...
- Page 8 1. Go to the Devices tab in the Ajax app 2. Select StreetSiren DoubleDeck from the list. 3. Go to Settings by clicking on the Note that after editing the settings, you should click the Back button to save them.
- Page 9 The volume level is measured 1 m away from the siren Determines how long the siren sounds in case Alarm duration of alarm: 3 to 180 seconds for each operation. Set in increments of 3 seconds Alarm when the accelerometer is triggered: the siren is triggered if you turn the body or detach the device from the mount.
- Page 10 Setting up the processing of detector alarms Through the Ajax app, you can con gure which detector alarms can activate the siren. This can help to avoid situations when the security system noti es of...
- Page 11 Setting the response to pressing the panic button in the Ajax app The siren can respond to pressing the panic button in Ajax apps. Note that the panic button can be pressed even if the system is not armed! For the siren to respond to pressing the panic button:...
- Page 12 The siren after-alarm indication does not work for always active detectors, if the detector was triggered when the system was disarmed. To enable the siren after-alarm indication, in Ajax PRO app 1. Go to siren settings: Hub → Settings → Service → Siren Settings 2.
- Page 13 Lid opening 3. Select the sirens needed. Go back to Siren Settings. The set parameters will be saved. 4. Click Back. All values will be applied. StreetSiren DoubleDeck with rmware version 3.72 and later supports this function. Indication Event Indication The siren emits an acoustic signal and the LED frame blinks red.
-
Page 14: Functionality Test
Attenuation Test Choosing a location The placement of StreetSiren DoubleDeck determines its distance from the hub and the presence of obstacles between them that impede the passage of the radio signal: walls, inter- oor constructions, or large-sized objects located in the room. -
Page 15: Installation
StreetSiren DoubleDeck runs on bundled battery for up to 5 years and is equipped with terminals for connecting 12V DC external power supply. The... - Page 16 3. Connect the cable to the terminal strips observing polarity. 4. Turn on power — the External Power Supply eld value changes to Connected in StreetSiren DoubleDeck statuses. 5. Install the siren. After connecting external power supply, do not remove the batteries from the siren: they act as a backup power source.
- Page 17 10. Fix the Brandplate to the protective plastic panel using the bundled bolt. 11. Fit the protective plastic panel in place (the Ajax logo on the connection side of the LED strip to the board) with little effort. The properly mounted plastic panel will protrude above the LED frame no more than 1.0 to 1.5 mm.
-
Page 18: Maintenance
Before mounting the siren, be sure to choose the optimal location that meets the requirements of this manual. The recommended installation height is 2.5 meters or more. This will make di culties for intruders to access the device. If you try to detach the device from the mount, the system will raise an alarm. -
Page 19: Technical Speci Cations
LED frame in the lower right corner will light up and go out when the system is arming and disarming (if the indication is disabled), when alarming, dismantling, or opening the siren body. What is the StreetSiren DoubleDeck batteries runtime and what does it affect How to replace batteries in StreetSiren DoubleDeck... -
Page 20: Complete Set
Up to 95% Dimensions 200 × 200 × 55 mm Weight 571 g Complete Set 1. StreetSiren DoubleDeck 2. SmartBracket mounting plate 3. CR123A battery (pre-installed) — 4 pcs 4. Mounting kit 5. Quick Start Guide Warranty The warranty for the “AS MANUFACTURING” Limited Liability Company products is valid for 2 years after the purchase and does not apply to the bundled rechargeable battery. - Page 21 User agreement Technical support: support@ajax.systems...
