Operating Principle - AJAX KeyPad Plus User Manual

11. Night mode button
12. SmartBracket mounting plate (to remove the plate, slide it down)
Do not tear off the perforated part of the mount. It is required for actuating the tamper in case of
any attempt to dismantle the keypad.
13. Tamper button
14. Power button
15. Keypad QR Code

Operating principle

00:00
KeyPad Plus arms and disarms the security of the entire facility or separate groups as well
as allows activating the Night mode. You can control the security modes with KeyPad Plus
using:
1. Passwords. The keypad supports common and personal passwords, as well as arming
without entering a password.
2. Cards or key fobs. You can connect
quickly and securely identify users, KeyPad Plus uses the DESFire® technology.
DESFire® is based on the ISO 14443 international standard and combines 128-bit
encryption and copy protection.
Tag key fobs and Pass cards
00:04
to the system. To
