5.2.2

Craft Port

The back panel craft port is primarily used to give the SiteDialer an IP address so you can continue the
rest of your database configuration over LAN. Use a terminal emulating software program like
HyperTerminal to enter the SiteDialer's TTY interface. Please see the Quick Start in the next section for
instructions.
To use the craft port, connect the included DB9 download cable from your PC's COM port to the craft
port.
5.2.3

LAN Connection

LAN is used for web browsing to the SiteDialer. You can also do your databasing over LAN, as well as
sending email notifications and SNMP traps. To connect the SiteDialer to the LAN, insert a standard
RJ45 Ethernet cable into the 10BaseT Ethernet port on the back of the unit. (See Fig. 5d) If the LAN
connection is OK, the LNK LED will light SOLID GREEN.
5.2.4

Telco Connection

The SiteDialer's telco connection is used for voice notifications. The rear panel telco jack (see Fig. 5d)
connects the SiteDialer to a standard telephone line. This will allow you to dial in / dial out from the unit.
5.2.5

LED Funtionality

LED
Craft Port
Power
Back Panel LEDs
Status
Blink Green
Blink Red
LAN Blink Yellow
LNK Solid Green
Solid Green
Off
Table 9.1. LED Functionality
Description
Transmit over craft.
Receive over craft.
Transmit and receive activity
over Ethernet port.
Ethernet link OK.
Power is connected to the
SiteDialer.
Power is disconnected from the
SiteDialer.
