Configuration
6.1
Craft Port
The DAC-P can be provisioned and configured either locally, through a craft port connection, or remotely, through a
LAN/WAN connection. However, some initial configuration must be done locally before you can access the DAC-P through
a network connection.
To make a local connection to the DAC-P, connect a DB9 serial cable from the COM port of your computer to the craft port
on the front panel of the DAC-P.
Select the following COM port options, as shown in Figure 8:
• Bits per second: 9600
• Data bits: 8
Fig. 7. The DAC-P craft port
Fig. 8. Port settings to connect to the DAC-P
