Installation and Operation

This section describes the installation and the operation of the DTP2 T 201 D extender
transmitters, including:
•
•
•
•
•
•

Mounting the Transmitter

ATTENTION:
The DTP2 T 201 D transmitters can be installed in a one-gang electrical wall box, or with a
mud ring, with a decorator-style wallplate cover (supplied).
The installation must conform to national and local building, electrical, and safety codes and
to the size requirements of the wall plate.

UL and Safety Guidelines

The following UL guidelines pertain to the installation of the decorator-style wallplate
transmitters into a wall or furniture.
•
•
•
•

Site Preparation and Wall Box Installation

Choose a location that allows cable runs without interference. Allow enough depth for both
the wall box and the cables. Install the cables into the wall, furniture, or conduits before
installing the wall plate.
NOTE: The decorator-style wallplate units are very deep and have connectors on the
Mounting the Transmitter
Transmitter Front Panel
Transmitter Rear and Bottom Panels
TP Cable Termination and Recommendations
Power Supply Wiring
Operation
Installation and service must be performed by authorized personnel.
•
• L'installation et l'entretien doivent être effectués par le personnel autorisé
uniquement.
These units are not to be connected to a centralized DC power source or used beyond
their rated voltage range.
These units must be installed in UL-listed wall boxes.
These units must be installed in a UL-listed junction box with a UL-listed faceplate.
This product is intended to be supplied by a power source marked "Class 2" or "LPS"
rated 12 VDC, minimum 1.5 A.
back side. Extron recommends a 1-gang wall box which has a depth of at least 3.0
inches (76 mm) to accommodate the connectors and cables.
DTP2 T 201 D Transmitter • Installation and Operation 4
