Installation and Operation

This section describes the installation and the operation of the DTP2 T 201 D extender transmitters, including:
•

Mounting the Transmitter

•
Transmitter Front Panel
• Transmitter Rear and Bottom Panels
•
Connection Details
• Operation
Mounting the Transmitter
ATTENTION:
•
Installation and service must be performed by authorized personnel.
•
L'installation et l'entretien doivent être effectués par le personnel autorisé uniquement.
The DTP2 T 201 D transmitters can be installed in a one-gang electrical wall box, or with a mud ring, with a
decorator-style wallplate cover (supplied).
The installation must conform to national and local building, electrical, and safety codes and to the size
requirements of the wall plate.

UL and Safety Guidelines

The following UL guidelines pertain to the installation of the decorator-style wallplate transmitters into a wall or
furniture.
•
These units are not to be connected to a centralized DC power source or used beyond their rated voltage
range.
•
These units must be installed in UL-listed wall boxes.
•
These units must be installed in a UL-listed junction box with a UL-listed faceplate.
•
This product is intended to be supplied by a power source marked "Class 2" or "LPS" rated 12 VDC, minimum
1.8 A.

Site Preparation and Wall Box Installation

Choose a location that allows cable runs without interference. Allow enough depth for both the wall box and the
cables. Install the cables into the wall, furniture, or conduits before installing the wall plate.
NOTE: The decorator-style wallplate units are very deep and have connectors on the back side. Extron
recommends a 1-gang wall box which has a depth of at least 3.0 inches (76 mm) to accommodate the
connectors and cables.
To install a new wall box, perform steps 1 through 8. If a suitable wall box is already installed, perform steps 5
through 8, starting below. UL-listed wall boxes are required.
1. Place the wall box against the installation surface, and mark the opening guidelines.
2. Cut out the material from the marked area.
DTP2 T 201 D • Installation and Operation 4
