User's Manual
Digital Video Transmitter and Receiver
DVI 201 Tx/Rx
HDMI 201 Tx/Rx
68-1034-01 Rev. C
07 06
Advertisement
Table of Contents
Related Manuals for Extron electronics DVI 201 Tx/Rx
Summary of Contents for Extron electronics DVI 201 Tx/Rx
- Page 1 Anaheim, CA 92805 3821 AH Amersfoort PM Industrial Building 16 Ichibancho 07 06 The Netherlands Singapore 368363 Chiyoda-ku, Tokyo 102-0082 Japan 714.491.1500 +31.33.453.4040 +65.6383.4400 +81.3.3511.7655 www.extron.com Fax 714.491.1517 Fax +31.33.453.4050 Fax +65.6383.4664 Fax +81.3.3511.7656 © 2006 Extron Electronics. All rights reserved.
-
Page 3: Table Of Contents
Table of Contents Chapter One • Introduction ............ 1-1 About this Manual ..............1-2 About the DVI 201 Tx/Rx and HDMI 201 Tx/Rx ....1-2 TP cable advantages .............. 1-3 Serial communications ............1-3 Transmission distance ............1-3 Features ..................1-4 Chapter Two •... - Page 4 Cables ..................A-9 Adapters .................A-9 Chapter One Introduction About this Manual About the DVI 201 Tx/Rx and HDMI 201 Tx/Rx Features 68-1034-01 Rev. C 07 06 All trademarks mentioned in this manual are the properties of their respective owners. DVI 201 and HDMI 201 Tx/Rx • Table of Contents...
-
Page 5: About This Manual
DVI or HDMI cable. These transmitter and receiver twisted pair (TP) products make cable The Extron DVI 201 Tx/Rx is a Digital Visual Interface (DVI) runs simpler and less cumbersome. Termination of the cable transmitter/receiver set. The HDMI 201 Tx/Rx is a High with RJ-45 connectors is simple, quick, and economical. -
Page 6: Features
XGA video over 200' (60 m), and 1080p HDTV or UXGA (1600 x 1200) over 125' (38 m). Local monitor output (DVI 201 Tx/Rx only) — The DVI 201 Tx transmitter features a DVI-D output for connection to local monitor. -
Page 7: Mounting The Tx/Rx
Installation Mounting the Tx/Rx Installation and service must be performed by VersaTools Rack Shelf authorized personnel only. The 1" high, quarter-rack width transmitters and receivers can be placed on a tabletop, mounted on a rack shelf, mounted under a desk or tabletop, or mounted on a projector bracket. Tabletop placement Affi... -
Page 8: Under-Furniture Mounting
Installation and Operation, cont’d Under-furniture mounting Through-furniture mounting The transmitter or receiver can be mounted under a table or The transmitter or receiver can be mounted through a desk or other horizontal surface using an optional Extron MBU 125 other furniture using an optional Extron MBD 129 through-desk under-desk mounting kit (part #70-077-01). -
Page 9: Projector Mounting
Installation and Operation, cont’d Slide the transmitter or receiver up and down in the Side Mounting PLate mounting brackets until the face of the transmitter or Countoured receiver is at the desired height. Tighten the screws that Bracket Brace secure the brackets in place. U-Bolt If the screws are inaccessible to a screwdriver: Extron... -
Page 10: Pmk 350 Mounting
Installation and Operation, cont’d Place the U-bolt around the ceiling pole and insert the Assemble the U-bolt and the following parts in the two legs of the U-bolt through the round holes on the following order (fi gure 2-8): contoured bracket base and then through the slotted holes a. -
Page 11: Connections
Installation and Operation, cont’d Connections Local output (DVI 201 Tx) — If desired, connect a DVI monitor for local monitoring of the input digital image. See DVI Transmitter connections connector pin assignments on page 2-14 for pin assignments. The two transmitter models are in quarter-rack width HDMI input connector (HDMI 201 Tx) —... -
Page 12: Receiver Connections
Installation and Operation, cont’d Receiver connections DC power input connector — Plug the included external The two transmitter models are in quarter-rack width 12 VDC power supply into either this 2-pole captive screw enclosures. connector or the power input connector on the transmitter (item on page 2-11). -
Page 13: Pin Assignments And Wiring
Installation and Operation, cont’d HDMI connector pin assignments Pin assignments and wiring Figure 2-14 defi ne the pinout for the HDMI protocol. DVI connector pin assignments Figure 2-13 defi ne the pinout for the DVI protocol. HDMI Male Connector HDMI Female Connector Type A Plug Type A Receptacle... -
Page 14: Tp Cable Termination
Installation and Operation, cont’d TP cable termination If necessary, test for proper cable connection (output 1 to input 1, output 2 to input 2) as follows: RJ-45 termination with CAT 5, CAT 5e, CAT 6, or CAT 7 cable must comply with the TIA/EIA T 568A wiring Plug both TP cables into the powered unit. -
Page 15: Power Supply Wiring
Installation and Operation, cont’d Peel the backing off the self-adhesive shielded aluminum tape and wrap it around the folded-over cable shielding, Smooth Ridges slightly overlapping the beginning of the tape (fi gure 2-17). SECTION A–A Wrap tape around folded foil shielding. Aluminum Tape Power Supply Slightly overlap. -
Page 16: Operation
Installation and Operation, cont’d Operation Transmitter control and indicator Power LED — This transmitter front panel LED lights to indicate that the unit is receiving power. DVI INPUT LOCAL OUTPUT DDC Route switch (DVI 201 Tx only) — This transmitter rear panel switch selects either the remote or local DVI display as the DVI 200 Tx SERIES route of the display resolution data (the display data channel... -
Page 17: Troubleshooting
Installation and Operation, cont’d • High-bandwidth Digital Content Protection (HDCP) is DVI 201 and HDMI 201 Tx/Rx an encryption method that protects copyrighted digital entertainment material that uses DVI video. HDCP is generated by video player hardware, enabled by the video content. The HDCP key is transmitted with the Display Data Channel (DDC). -
Page 18: Specifi Cations
Digital audio ........ HDMI* audio, actively buffered Specifi cations (transmitted through RGB and YCrCb DVI 201 Tx/Rx Specifi cations lines) *An optional HDMI to DVI adapter is required if an HDMI signal is This product consists of a transmitter (DVI 201 Tx) and a receiver used. -
Page 19: Hdmi 201 Tx/Rx Specifi Cations
Reference Information, cont’d General HDMI 201 Tx/Rx Specifi cations External power supply ....100 VAC to 240 VAC, 50/60 Hz, external, This product consists of a transmitter (HDMI 201 Tx) and a receiver autoswitchable; to 12 VDC, 1 A, regulated (HDMI 201 Rx) with twisted pair cables linking the transmitter and Power input requirements ... - Page 20 Reference Information, cont’d Digital audio ........ HDMI audio, actively buffered Enclosure type ......Metal (transmitted through RGB and YCrCb Enclosure dimensions ....1.0" H x 4.3" W x 3.0" D lines) (quarter rack wide) RS-232 ..........RS-232 serial data (pass-through) (on a 3.5 2.5 cm H x 10.9 cm W x 7.6 cm D mm captive screw connector, 3 pole) (Depth excludes connectors.)
-
Page 21: Part Numbers
MBU 125 under-desk mount kit 70-077-01 Included Parts MBD 129 through-desk mount kit 70-077-02 These items are included in each order for a DVI 201 Tx/Rx or PMK 300 projector mount kit 70-374-03 HDMI 201 Tx/Rx: PMK 350 low profi le projector mount kit... - Page 22 Reference Information, cont’d A-10 DVI 201 and HDMI 201 Tx/Rx • Reference Information...
-
Page 23: Chapter One
In no event will Extron Electronics be liable for direct, indirect, or consequential representar riesgo de electrocución. Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal califi...
