CA/CE-Series GigE Area Scan Camera·User Manual
7. (Optional) Enable Periodically Send to enable the client to send commands periodically.
8. (Optional) Enter proper value in Sending Interval.
The default value is 1000 ms, and valid value range is from 1 ms to 3600000 ms.
9. (Optional) Enable Request Acknowledgement to display the acknowledgement messages.
Up to 50 messages can be displayed. Once the message quantity exceeds 50, the earliest message
will be automatically deleted.
10. Click Start Sending.
If you want to send action commands that are executed in multiple cameras at exactly the same
time, it is recommended to enable Gev IEEE 1588 first by clicking Transport Layer Control > Gev
IEEE 1588.

7.9 Color Transformation Control

The camera supports Color Correction Matrix function that is designed to restore color and
eliminate the overlap in the color channels caused by the fact that Blue light is seen by the Red and
Green pixels on the imager, Red light is seen by the Blue and Green pixels, and Green light is seen
by the Red and Blue pixels.
Steps:
1. Click Color Transformation Control.
2. Enable Color Transformation Enable.
3. Select Color Transformation Selector according to actual demands.
Figure 7-24 Set Color Transformation Control
34
