If the 1st frame image's exposure time of the 2nd trigger signal is not earlier than the camera's last
frame creation time of the 1st trigger signal, and then the 2nd trigger signal's 1st frame image is
created normally.
If the 1st frame image's exposure time of the 2nd trigger signal is earlier than the camera's last
frame creation time of the 1st trigger signal, and then the camera will delay this exposure time.
Thus making sure this exposure time is not earlier than the camera's last frame creation time of
the 1st trigger signal.

7.5.4 Set Trigger Activation

The camera supports trigger acquisition in the rising edge, falling edge, level high, or level low of
the external signal. The principle and parameter of trigger activation are shown below.
Trigger Activation
Rising edge
Falling edge
Level High
Level Low
CA/CE-Series GigE Area Scan Camera·User Manual
Table 7-5 Trigger Activation Principle and Parameter
Parameter
Acquisition Control >
Trigger Activation
Acquisition Control >
Trigger Activation
Acquisition Control >
Trigger Activation
Acquisition Control >
Trigger Activation
Parameter Value
Rising Edge
Falling Edge
Level High
Level Low
29
Principle
Rising Edge refers to the rising
edge of the trigger signal is
valid, that is camera exposure
and acquisition at the
beginning of the rising edge of
the trigger signal.
Falling Edge refers to the falling
edge of the trigger signal is
valid, that is camera exposure
and acquisition at the
beginning of the falling edge of
the trigger signal.
Level High refers to the level
high of the trigger signal is
valid. As long as trigger signal is
in level high, the camera keeps
exposure and acquisition
status.
Level Low refers to the level
low of the trigger signal is valid.
As long as trigger signal is in
level low, the camera keeps
exposure and acquisition
status.
